ASE2-LCD 2 ton Automatic advance function type water softener valve with empty salt cabinet technology

1). Automatic advance water softener valve Upflow type with empty salt cabinet technology .
2). Upflow Working Position :
a). Refill before regeneration: Service->Refill the softener water->Service->Back Wash->Upflow Brine and slow rinse->Fast rinse->Service .
b). Refill after regeneration: Service->Back Wash->Upflow Brine and slow rinse->Fast rinse->Refill the softener water->Service .
3). Using ceramic movig valve disk, small rotation torque.
4). Abrasion resistance of sealing surface, outstanding and long -lived deal .
5). It could be operated with pressure directly .

Inlet 1/2'' 3/4'' 1''
Outlet 1/2'' 3/4'' 1''
Drain 1/2''
Base 2-1/2''
Riser pipe 1.05''OD
Water Capacity 2m³/h
Working Pressure 0.15-0.6MPa
Working Temperature 5-50℃
  • ASE2-LCD

  • Keman

  • 84212110

  • Material: PPO or ABS
  • Control mode: Automatic
  • Capacity: 2 ton / hour
  • Applied range: Water softener machine / industrial softener
  • Installation Method: Cabinet
  • Voltage: 220/110
  • Power: 18W
Quantity:

Model number :  ASE2-LCD :

2 ton Automatic advanced function upflow water softener valve with refill the softener water and empty salt cabinet technology.



Product introduce :

1). Automatic advance water softener valve Upflow type  with empty salt cabinet technology.
2).Upflow Working Position :
     a). Service->Refill the softener water->Service->Back Wash->Upflow Brine and slow rinse->Fast rinse->Service .
     b). Service->Back Wash->Upflow Brine and slow rinse->Fast rinse->Refill the softener water->Service .

3). Using ceramic moving valve disk, small rotation torque .

4). Abrasion resinstance of sealing suface, outstanding and long-lived deal .

5). It could be operated with pressure directly .

6). ASE2 are automatic softener valves, LCD display or LED display .


Model: Automatic softener  Valve ASE2 -LCD/LED
Refilling type     refill before regeneration   refill after regeneration
Working Position
Service->Refill the softener water->Service->Back Wash->Upflow Brine and slow rinse->Fast rinse->Service

Service->Back Wash->Upflow Brine and slow rinse-> Fast rinse-> Refill the softener  water->Service
Regeneration mode Automatic type
Meter Delay
Intelligent Meter Delay
Timer by day :  0-99 days
Timer by hours: 0-99 hours
Automatic type
Meter Delay
Meter immediate
Intelligent Meter Delay
Intelligent Meter Immediate
Timer by day :  0-99 days
Timer by hours: 0-99 hours
Inlet 1/2''  3/4''  1''
Outlet 1/2''  3/4''  1''
Drain 1/2''
Base 2-1/2''
Riser pipe 1.05'' OD
Water Capacity 2m3/h
Working Pressure 0.15-0.6Mpa
Working Temperature 5-50°C
Power Supply AC100-240 / 50-60Hz     /       DC12V-1.5A
Working Principle :
ASE2

  • Applied range
